10 CHAPTER 1: OVERVIEW
Ethernet Interface
Table 5 lists attributes of the Ethernet interface.
Synchronous/Asynchronous Serial Interface
Table 6 lists attributes of the synchronous/asynchronous serial interface.
Protocols PPP (Point to Point Protocol)
SLIP (Serial Line Internet Protocol)
MP (Multilink PPP)
Tabl e 5 Attributes of the Fast Ethernet Interface
Attribute Description
Connector RJ45
Frame format Ethernet_II
Ethernet_SNAP
IEEE 802.2
IEEE 802.3
Operating mode 10/100Mbps autosensing
Full duplex/half duplex
Network protocol IP (Internet Protocol)
Novell IPX (Internet Packet Exchange)
Tabl e 6 Attributes of the Synchronous/Asynchronous Serial Interface
Attribute
Description
Synchronous Asynchronous
Connector DB50
Interface standard
and operating
mode
V.24
(EIA/TIA-23
2)
V.35 EIA/TIA-449, X.21 and
EIA-530
V.24 (EIA/TIA-232)
DTE, DCE DTE, DCE DTE DCE
Minimum baud
rate (bps)
1200 1200 1200 1200 300
Maximum baud
rate (bps)
64 k 2.048 M 2.048 M 2.048 M 115.2 k
Services DDN leased line
Terminal access
Backup
Modem dial-up
Backup
Protocols PPP
MP
LAPB (Link Access Protocol-Balanced)
HDLC (High-level Data Link Control)
SDLC (Synchronous Data Link Control)
X.25
Frame Relay
PPP
SLIP
MP
Table 4 Attributes of the AUX Port
Attribute Description
