12 CHAPTER 1: OVERVIEW
LEDs Table 8 lists and describes the LEDs on the front panel of the Router 3013 and
Router 3015.
Interface Attributes The Router 3013 and Router 3015 provide a console port, an AUX port, a
10/100M Ethernet interface, a synchronous/asynchronous serial interface, and an
ISDN S/T or U port.
Console Port
Table 9 lists attributes of the console port.
Weight 0.75kg (1.65lb)
Operating
temperature
0 to 40C (32 to 104
0
F)
Operating
humidity
5 to 85% (noncondensing)
Table 7 System Specifications for the Router 3013 and Router 3015 (continued)
Item Router 3013 Description Router 3015 Description
Tabl e 8 Router 3013 and Router 3015 LEDs
LED Description
POWER Off means that power is not being supplied.
Green means that power is being supplied.
100M ETH Off means that the link is not connected.
Flashing green means that data is being sent or received over the
Ethernet interface.
SERIAL Off means that the link is not connected.
Green means that the link is connected.
Flashing green means that data is being sent or received over the
synchronous/asynchronous port.
BRI Off means that no data is being sent or received over the ISDN BRI
port and two B channels are free.
Flashing green means that data is being sent and received over the
ISDN BRI port.
AUX Off means that the link is not connected.
Green means that the link is connected.
Flashing green means that data is being sent or received over the
AUX port.
SYSTEM Flashing green means that the system is properly working.
Always green or off means that the system is incorrectly working.
Tabl e 9 Attributes of the Console Port
Attribute Description
Connector RJ45
Interface standard Asynchronous EIA/TIA-232
Baud rate 9600 to 115200bps (9600bps is the default)
