3DR DIY Y6 - Assemble Propeller Adapters; Add Propellers

23
2 Assemble propeller adapters
Select the propeller adapters and
the longer screws provided with the
adapters. Do not use the x-shaped
plate. Apply threadlocker to the four
small screws included with the
propeller adapters (less than one
drop covering four to five threads).
Attach an adapter to the top of each
motor.
3 Add propellers
Your Y6 uses SF and SFP propellers.
These propellers are labelled on the
package and on the propeller itself.
Add SF and SFP propellers to the
motors shown in the diagram below
with the writing on the propeller
facing towards the sky. The right
propeller order and orientation is
critical for your copter to fly correctly.
Add the spacer above the propeller,
and secure the nut tightly on top.
Ensure that the writing on the propellers for both
top and bottom motors faces the sky.
