3DS MAX Series User Manual

6.操作及显示
Mode
5.1
Other description
Units are placed after the numbers:
Hours (H), Minutes (M), Seconds (S), Voltage (V)
Load on, discharge
Indicate low voltage protection、25%、50%、
5. Operation
Page 3 of 10 pages
Key function
Operating
Browse interface
Short press OK.
Static display
Press the MENU and OK key at the same time for 1s, the LCD screen will lock
the interface. unlock and start scrolling.Press the OK key , the LCD interface will
Setting parameter
Press the MENU key for 1s to enter the setting mode when the icon
interface, and exit automatically after 30s.appears on the display
Load On/Off
When the controller is working in street lamp mode, press the MENU key for
load, press the MENU key again or 1min later the load will 3s to turn on the
5.2 LCD Display
5.2.1 Status Description
Item
Icon
Status
PV array
Daytime, charging
Battery
Battery capacity
Load
Solar charge controller MAX series User Manual
be turned off.
75%、100%
