3M 10800 - Page 39

NA - ENG
April 2017
3M-Matic
™
Accuglide 3 - 2 Inch Taping Head
Page 31
Ref. No. 3M Part No. Description
10923-1 78-8137-3302-5 Link – Assembly
10923-3 78-8137-3304-1 Shaft – Pivot, Buffi ng
10923-4 78-8017-9082-1 Bearing – Special 30 mm
10923-5 78-8017-9106-8 Screw – Bearing Shoulder
10923-6 26-1003-5829-5 Screw – Hex Hd, M6 x 12
10923-7 78-8137-3305-8 Spacer – Applying Pivot
10923-8 78-8137-3306-6 Shaft – Pivot, Applying
10923-9 78-8094-6151-6 Washer - Flat, 6.5 ID x 15 OD x 0.5 Thk
Figure 10923 – 2" Upper and Lower Heads
AccuGlide
™
3 - 2"
