3M 10800 - Page 43

NA - ENG
April 2017
3M-Matic
™
Accuglide 3 - 2 Inch Taping Head
Page 35
Figure 10401 – 2" Latch Upper and Lower Heads
Ref. No. 3M Part No. Description
10401-1 78-8070-1395-4 Bracket – Bushing Assembly
10401-2 78-8076-4519-3 Shaft – Tape Drum, 50mm
10401-3 78-8017-9169-6 Nut – M18 x 1
10401-4 78-8098-8827-0 Tape Drum Sub Assembly – 2 Inch Wide
10401-5 78-8098-8749-6 Tape Drum
10401-6 78-8098-8817-1 Leaf Spring
10401-7 26-1002-5753-9 Screw – Self Tapping
10401-8 78-8060-8172-1 Washer – Friction
10401-9 78-8052-6271-0 Washer – Tape Drum
10401-10 78-8100-1048-4 Spring – Core Holder
10401-11 78-8017-9077-1 Nut – Self Locking, M10 x 1
10401-12 78-8100-1046-8 Spacer – Bracket
10401-13 26-1003-5829-5 Screw – Hex Hd, M6 x 12
10401-14 78-8098-8814-8 Tape Drum Assembly – 2 Inch Head
10401-15 26-1004-5510-9 Washer – Plain, M10
10401-16 78-8098-8816-3 Latch – Tape Drum
AccuGlide
™
3 - 2"
