3M 10800 - Page 45

NA - ENG
April 2017
3M-Matic
™
Accuglide 3 - 2 Inch Taping Head
Page 37
Figure 10924 – 2" Lower Head
Ref. No. 3M Part No. Description
10924-1 78-8137-3296-9 Frame – Tape Mount Lower Assembly
10924-2 78-8137-3297-7 Frame – Front Lower Assembly
10924-3 78-8068-4144-7 Guide – #2
10924-4 78-8068-4143-9 Guide – #1
10924-5 78-8060-7818-0 Screw – Hex Hd, M4 x 12
10924-6 78-8010-7416-8 Nut – Hex, M4
10924-7 78-8070-1251-9 Spacer – Spring
10924-8 78-8054-3298-5 Spacer – 10 x 10 x 90 mm
10924-9 78-8052-6560-6 Spacer – Front
10924-10 78-8060-7936-0 Brush Assembly
10924-11 78-8052-6564-8 Shaft – Tension Roller
10924-12 78-8052-6568-9 Shaft – Wrap Roller
10924-13 26-1003-5829-5 Screw – Hex Hd, M6 x 12
10924-15 78-8100-1009-6 Washer – Special
10924-16 78-8052-6606-7 Roller – Tension Bottom
10924-17 26-1004-5510-9 Washer – Plain, M10
10924-18 78-8052-6567-1 Spring – Compression
10924-19 78-8017-9077-1 Nut – Self Locking, M10 x 1
10924-20 78-8052-6569-7 Roller – Wrap
10924-21 26-1000-1613-3 Ring – Retaining, Tru-Arc #1-420-0120-100
10924-22 78-8076-4500-3 Stud – Mounting (not shown)
10924-23 78-8076-5242-1 Stop – Cut-Off Frame
10924-24 78-8060-8179-6 Screw – Flat Hd Hex, M6 x 20
10924-25 78-8076-5477-3 Washer – Special /6.5 x 20 x 4
10924-26 78-8137-3299-3 Guard – Head
10924-27 78-8060-8087-1 Screw – M5 x 10
10924-28 78-8005-5741-1 Washer – Flat, M5
10924-29 78-8076-4734-8 Bumper
10924-30 78-8133-9606-2 Label – Threading, English Language
10924-31 78-8076-4716-5 Star Washer 4mm
AccuGlide
™
3 - 2"
