3M 10800 - Page 47

NA - ENG
April 2017
3M-Matic
™
Accuglide 3 - 2 Inch Taping Head
Page 39
Figure 10920– Lower Head
Ref. No. 3M Part No. Description
10920-1 78-8137-3300-9 Buffi ng Arm – Sub Assembly
10920-2 78-8137-3301-7 Buffi ng Arm – Sub Assembly
10920-3 78-8052-6575-4 Shaft – Roller
10920-4 78-8137-1398-5 Roller - Buffi ng Assembly
10920-5 78-8070-1220-4 Spacer – Spring
10920-6 78-8052-6580-4 Spacer
10920-7 26-1003-5829-5 Screw – Hex Hd, M6 x 12
10920-8 78-8137-3312-4 Spring – Lower (100 fpm)
10920-9 78-8070-1244-4 Holder – Spring
AccuGlide
™
3 - 2"
