3M™ Overhead Projector 1800 Illustrated Parts Breakdown
© 3M 2007 11
Section 4. Arm Assembly
(Serial number 18040827 and below, North & South America only)
Arm Assembly Parts List
(Serial number 18040827 and below, North & South America only)
Item 3M Part Number Description Qty.
1A 78-8120-8575-7
Arm Kit (includes rectangular post)
Note: When stock runs out, replacement is XO-0038-1808-5
1
1B 78-8120-8576-5 Arm / Offset Post Kit (rectangular post) 1
2 - - - Arm, Focus (Order Arm Kit 78-8120-8575-7) 2
3 78-8120-4017-4 Pad, Tension 1
4 78-8120-3069-6 Pad 1
5 78-8120-3142-1 Cap, Focus 1
6 - - - Knob, Focus Gear, Blue (Order Arm Kit 78-8120-8575-7) 1
7 78-8079-8744-7 Rack, Focus 1
8A 78-8120-8513-8 Rectangular Post, Inverted Arm 1
8B 78-8120-8514-6 Rectangular Post, Basic Arm 1
9 78-8120-8537-7 Arm / Post / with Inverted Singlet Head Assembly (Not shown) 1
3
8
2
5
6
7
4
1
