3M 1810 User Manual

3M™ Overhead Projector 1800 Illustrated Parts Breakdown
© 3M 2007 6
Section 0. Machine Overview
Head Assembly
(See Sections 1, 2, and 3)
Top Cover Assembly
(See Sections 8 and 9)
Arm Assembly
(See Sections 4 and 5)
Base Assembly
(See Section 10)
ENX/FXL Lamp Housing
(Single and Dual)
(See Sections 11 and 12)
FNT Lamp Housing
(Single and Dual)
(See Sections 13 and 14)
EVD Lamp Housing
(Dual)
(See Section 15)
Lamp Assembly
(See Section 16)
Cooling Fan Assembly
(See Section 17)
Roller Kit
(See Section 18)
Wire Jumpers
(See Sections 19 and 20)
Plastic Parts Kit
(See Section 21)
Electrical Parts Kit
(See Section 22)
Post Mounting Hardware
(See Section 6 and 7)
Open Closed Inverted

3M 1810 Specifications

General

Brand	3M
Model	1810
Category	Projector
Language	English
