3MModel 2100 Overhead Projector
Illustrated Parts Breakdown
3
3M 1992
Section 1
OVERVIEW
Projection Head Assemblies
(See Sections 2, 3 and 4)
Focus Mechanism Assemblies
(See Sections 5 and 6)
Top Cover Assemblies
(See Section 7)
Base Assembly
(See Section 8)
Fixed Post Assembly
(See Section 9)
Lamp Module Assemblies
(See Sections 11 and 12)
Post Pivot Assembly
(See Section 10)
Roller Attachment (Not Shown)
(See Section 14)
Wire Jumpers/Harness (Not Shown)
(See Section 13)
