3M 2470 - System Mode Selection

Performance Series
Initializing the System
9
Initializing the System
System Mode Selection:
Before starting the system Initialization process, you must determine the mode of operation. Check the number of
speakers at each Multiple Product Dispenser (MPD). Typically, each active side of the MPD is identified as a
separate pump:
Number of Speakers
at MPD Mode of Operation to Use
1 Island Mode
2 Pump Mode
Table 2. Determining Mode of Operation
Figure 10. Pump Mode and Island Mode
