3M 718 - Parts Included

11
7.0 Parts Included
Static Sensor 718
1 ea. Static Sensor 718
1 ea. 718/718A User’s Guide
Air Ionizer Test Kit 718A
1 ea. Charge Plate Assembly 718A
1 ea. Charger 718A
1 ea. 718/718A User’s Guide
3M
™
Air Ionizer Test Kit 718A
Description Typical Value
Charge Plate Assembly Per ESD Association Draft Standard ANSI/ESD SP3.3
Aluminum bracket
Bare stainless steel plate
Teflon spacers isolate plate from bracket
Charge Plate Area 3.25" W x 1.25" L
8.3 cm W x 3.2 cm L
Charge Plate Assembly Weight 2.5 oz (70 g)
Charger Dimensions 0.87" H x 2.4" W x 4.9" L
2.2 cm H x 6.1 cm W x 12.4 cm L
Charger Weight 5 oz. (140 g) with battery
Charger Power Requirements One 9 volt alkaline battery
Charger Output
(using Static Sensor 718 with
charge plate)
1.1kV minimum for positive or negative voltage
Certifications cULus, CE
3M
™
Static Sensor 718 - continued
Description Typical Value
Voltage Output Jack 3/32 in. (2.5 mm) monophone
Tip: signal
Sleeve: ground
Voltage Output 1/1000 of measured voltage @ low range
1/10,000 of measured voltage @ high range
Automatic Shut-off 20 minutes after last switch activity
Distance Indicator LED targets. Aligned targets indicate 1 in.
(2.54 cm) measurement distance
Measurement Accuracy Within 5% of measured voltage
Measurement Stability ± 10 counts
Certifications cULus, CE
