3M Dynatel 900 Series User Manual

Care & Maintenance
Section 4
Page 84
Check RFL Performance Flowchart
Hookup (to Cable
Self Test Circuit):
R
B
G
Y
Res
Fault
Locate
On
Reset
Turn unit on.
Stored setups ––
Change setups
Measure DTS, or
DTS known
Temperature entry
option
Select cable gauge
Select hookups
Use separate good
pair hookup
continued on next page...
Setups summary
The display summarizes
the setups you just entered.
Press
✽ to use them.
The display may tell you
to “wait” while the unit
runs tests.
When you complete the
hookup, press
✽ to begin
the
measurements.
Test set, straps
hookup instruction
Fault resistance,
strap checks
Display distance in
units of feet or meters
Press the ✽ (star key) to use the
temperature default (21.1
° C or
70
° F)
Press the
✽ (star key) to choose
Measure DTS
Use arrow keys to
line up ✽ with 19
AWG or .912mm
OR
OR
