3M MPro120 User Manual

3M
™
Pocket Projector MPro120
© 2009 3M. All Rights Reserved. 7
English
Safety Labels
X X X X X X X X X X X X X X X X X X X
LITHIUM ION POLYMER BATTERY
Model No. BLP508-001
3.7V 2200mAh 8.1Wh
P/N 78-6972-0004-2
m Warning
• Use a specified charger.
• Do not throw the battery into fire or heat.
• Do not short-circuit the battery terminals.
• Do not disassemble the battery.
Charging Specification
Standard Charge 0.44A/4.2V
Cut Off Current 44mA
Max Charge 2.2A/4.2V
Cut Off Current 44mA
LED Light Output
CLASS 1 LED PRODUCT IEC60825-1 :1993+A1 :1997+A2:2001
Maximum Radiant Power:
0.59 mW

3M MPro120 Specifications

General

Projection technology	LCD
Screen size compatibility	50 \
Projector native resolution	VGA (640x480)
RMS rated power	1 W
Number of built-in speakers	2
Plug and Play	Yes
Mean time between failures (MTBF)	20000 h
Dimensions (WxDxH)	58 x 25 x 119 mm
Product type	-
Market positioning	Portable

Weight and Dimensions

Weight	159 g
