9
Ports and Cables
Refer to the table below to find out which projector port and cable to use for connecting a
given device. Use this table for determining which cables to prepare.
About Plug-and-Play Capability
• This projector is compatible with VESA DDC 1/2B. Plug-and-Play can be achieved by
connecting this projector to computers that are VESA DDC (display data channel)
compatible. Please take advantage of this function by connecting the accessory RGB
cable to the RGB IN port (DDC 1/2B compatible). Plug-and-Play may not work
properly if any other type of connection is attempted.
• Plug-and-Play is a system composed of the computer, its operating system and
peripheral equipment (i.e. display devices).
• Please use the standard drivers as this projector is a Plug-and-Play monitor.
NOTE
Function Projector Port Connection Cables
RGB input RGB IN
RGB cable
with D-sub 15-pin shrink jack and
inch thread screws
AUDIO input
(from the computer)
AUDIO IN Audio cable with stereo mini jack
RS-232C communication CONTROL RS-232C cable
S-video input S-VIDEO IN
S-video cable
with mini DIN 4-pin jack
Video input VIDEO IN Audio/video cable
Component video input
COMPONENT VIDEO Y
Component video cableCOMPONENT VIDEO C
B
/P
B
COMPONENT VIDEO C
R
/P
R
Audio input
(from video equipment)
AUDIO IN L
Audio/video cable or
Audio cable with RCA jack
AUDIO IN R
To Next Page
