PICTURE-1 Menu
PICTURE-2 Menu
With the PICTURE-1 menu, the five items shown in the Table
below can be performed.
Perform each operation in accordance with the instructions in the
Table.
With the PICTURE-2 menu, the four items shown in the Table
below can be performed.
Perform each operation in accordance with the instructions in the
Table.
Item Description
COLOR BAL R
Adjust Red Color Balance: Dark ⇔ Light
COLOR BAL B
Adjust Blue Color Balance: Dark ⇔ Light
SHARPNESS
Adjust Sharpness (for VIDEO/S-VIDEO): Clear ⇔ Soft
COLOR
Adjust COLOR (for VIDEO/S-VIDEO/COMPONENT VIDEO):
Dark ⇔ Light
TINT
Adjust Tint (for VIDEO/S-VIDEO): Green ⇔ Red
PICTURE-1 Menu
Item Description
V POSITION
Adjust Vertical Position (for RGB): Up ⇔ Down
H POSITION
Adjust Horizontal Position (for RGB): Left ⇔ Right
H PHASE
Adjust Horizontal Phase (for RGB/COMPONENT VIDEO):
Right ⇔ Left
• Adjust to eliminate flicker.
H SIZE
Adjust Horizontal Size (for RGB): Large ⇔ Small
• If the horizontal size adjustment is excessive, the image may not be displayed
correctly. In such a case, initialize H SIZE with the RESET button.
25
PICTURE-2 Menu
Example : PICTURE-1 Menu
(COLOR BAL R)
Example : PICTURE-2 Menu
(V POSITION)
MENU
: SELECT
MAIN
PICTURE-1
PICTURE-2
INPUT
SCREEN
OPTION
COLOR BAL R
COLOR BAL B
SHARPNESS
COLOR
TINT
12
MENU
: SELECT
MAIN
PICTURE-1
PICTURE-2
INPUT
SCREEN
OPTION
V POSITION
H POSITION
H PHASE
H SIZE
12
