17
Table 1 – Specications
Performance Specications:
SRL-LE Specications (Vertical) CSA Models OSHA Models
Capacity Range 59 kg - 140 kg (130 lbs - 310 lbs) 141 kg - 191 kg (311 lbs - 420 lbs)
Maximum Arresting Force 6.0 kN (1,350 lbs) 8 kN (1,800 lbs)
Average Arresting Force 4.0 kN (900 lbs) N/A
Claimed Maximum Arresting Distance
1
1.07 m (3.5 ft) 1.07 m (3.5 ft)
Minimum Fall Clearance Required
1
1.8 m (6 ft) 2.44 m (8 ft)
Maximum Free Fall
2
(0 m) 0 ft
SRL-LE Specications (Horizontal) CSA/OSHA Models
Capacity Range 59 kg - 140 kg (130 lbs - 310 lbs)
Maximum Arresting Force 6 kN (1,350 lbs)
Average Arresting Force 4 kN (900 lbs)
Claimed Maximum Arresting Distance
1
2.1 m (7 ft)
Minimum Fall Clearance Required 4.2 m (14 ft) when falling over an edge.
Maximum Free Fall
2
1.5 m (5 ft)
Minimum Setback Distance 0 m (0 ft), 0.6 m (2 ft) for WrapBack models
1 Assumes the SRL is mounted directly above (overhead) the end user.
2 Free Fall: Correct application of the SRL, with the user working directly below the anchorage point and no lifeline slack, will eliminate Free Fall. Free Fall should be
limited to 0.6m (2 ft) where the user is not directly under the SRL or minimal slack exists in the lifeline.
