3M Series 52 - Series 56 ZZ HVLP Connection Diagram

14
General Set Up and Spray Gun Use cont.
3M™ Series 56ZZ HVLP Automatic Spray Gun Connection Diagram
Mounting Hole
Atomizing Air Inlet
Trigger Air Inlet
Fluid Control
Fluid Inlet
Fluid Inlet
Fan Control Air Port
Series 56ZZ-2
Dual Fluid Inlet
Adjustable Fluid
Control
3
