3M SFT-200 - Page 33

Bypass Valve
V3191-01 Vertical Adapter Assembly
Drawing No. Description Quantity
Order No. Description Quantity
1 Nut 1” Quick Connect 2
V 3151 Nut 1” Quick Connect
V 3150 Split Ring
V 3105 O-Ring 215
V 3105 Vertical Adapter
2
2
2
2
1 Split Ring 2
1 O-Ring 215 2
1 Bypass 1” Rotor 2
1 Bypass Cap 2
1 Bypass Handlenect 2
1 Bypass Rotor Seal Retainer 2
1 O-ring 135 2
1 O-ring 112 2
1 O-ring 214 2
