PRODUCT OVERVIEW
The M100 Stopswitch is a simple inductive proximity shaft speed monitoring device. The self-contained
unit has a single set point, which signals when the shaft has stopped rotating. It can be used for
process control, motion detection and stopped shaft indication.
An inductive sensing device located in the nose of the M100 enclosure will detect a metal target. This
target can be an existing bolt head or device attached to a shaft. The M100 Stopswitch requires no
calibration and provides an output when the shaft has stopped rotating.
Ideally, the target should be a ferrous metal, but non-ferrous metal will be detected at a shorter range.
Maximum range for ferrous targets is 5/16 in. (8 mm) and for non-ferrous targets it is 3/16 in. (5 mm),
assuming a 3/4 in. (19 mm) diameter target. Smaller targets may be used but operating distances will
be reduced.
The unit incorporates a start-up delay of 4 seconds to allow moving parts to achieve correct speed,
thereafter, if a pulse is not received within 4 seconds an output stopped motion signal is indicated.
SPECIFICATIONS
Supply 24 to 240 Volts AC/DC (50/60 Hz)
Switching Capacity 200 mA Maximum
Saturation Voltage 8 Volts Maximum (Output On)
Leakage Current 1.6 mA Maximum (Output Off)
Operating Temperature -13°F (-25°C) to +158°F (+70°C)
Relative Humidity 90% RH
Sensing Range
Ferrous Target - 5/16 Inch (8 mm) Maximum
Non-Ferrous Target - 3/16 Inch (5 mm) Maximum
Enclosure Nylon - ISO Threaded 18 mm by 1 mm Pitch
Cable 6 ft. (2 m), 2 Conductor
Output State
Normally Closed (Volt Drop 8 Volts Max.) Above Minimum Input Speed
Normally Open (Leakage Current 1.6 mA Max.) at Stopped Motion
Input Pulse Range 20 to 2,000 PPM Maximum
Start Up Delay 4 Seconds
Trip Point Stopped Motion if No Input Received for a Period of 4 Seconds
LED Indicators (2)
Red (Input) = Target Sensed
Green (Output) = Closed Circuit
Protection IP67
Approvals
CSA Class II Division 1 Groups E, F and G (USA & Canada)
ATEX & CE Versions Available (Europe)
WARNING AVERTISSEMENT
• Rotating machinery can cause serious injury or death
• Always lockout and tagout the machine prior to installation
• Les machines en rotation peuvent provoquer des blessures graves, voire la mort.
• Toujours verrouiller et étiqueter la machine avant l’installation
