4BARCODE Technology 4B-2044A Series User Manual

Gap/Black Mark
Sensor Calibration
1. Turn off the power switch.
2. Hold on the button then turn on the power switch.
3. Release the button when LED turns red after 5
green/amber blinks. (Any red/amber will do during the 5
blinks).
 The LED color will be changed as following order.
The LED color will be changed as following order：
Blue red (5 blinks) purple (5 blinks)  blue (5
blinks) solid blue
Gap/Black Mark
Sensor Calibratio,
Label Length
Measurement,
Self Test and enter
Dump Mode
1.Turn off the power switch.
2. Hold on the button then turn on the power switch.
3. Release the button when LED becomes purple and blinking.
(Any amber will do during the 5 blinks).
 The LED color will be changed as following order.
The LED color will be changed as following order：
Blue red (5 blinks) purple (5 blinks) blue (5
blinks) solid blue
 It calibrates the sensor and measures the label length
and prints internal settings then enter the dump mode.
Note:
Please select gap or black mark sensor by GAP or BLINE
command prior to calibrate the sensor.
For more information about GAP and BLINE command,
please refer to TSPL2 programming manual.
