4BARCODE Technology 4B-2044A Series User Manual

Printer
Initialization
1.Turn off the power switch.
2. Hold on the button then turn on the power switch.
3 Release the button when LED becomes bule and blinking.
(Any red will do during the 5 blinks).
 It will calibrate the gap/black mark sensor sensitivity.
 The LED color will be changed as following order：
Blue red (5 blinks) purple (5 blinks) blue (5
blinks) solid blue
 It calibrates the sensor and measures the label length.
Skip AUTO.BAS
35
1. Turn off printer power.
2. Press the FEED button and then turn on power.
3. Release the FEED button when LED becomes solid bule.
 The LED color will be changed as following:
Amberred (5 blinks)purple (5 blinks)bule (5
blinks)solid bule
4. Printer will be interrupted to run the AUTO.BAS program.

4BARCODE Technology 4B-2044A Series Specifications

General

Brand	4BARCODE Technology
Model	4B-2044A Series
Category	Barcode Reader
Language	English
