4IPNET EAP757 - Page 11

User’s Manual
Enterprise Access Point ENGLISH
10
Copyright © 4IPNET, INC.
6
LED Indicators
Power
On indicates power on.
Status
On indicates the system is ready.
WLAN
On indicates wireless network interface is ready for service.
WES
For indicating WDS connection status.
Master (Press for more
than 3 seconds)
Slave (Press once and
then release right
away)
WES Start
LED (Green) OFF and
then BLINKING SLOWLY
LED (Green) BLINKS
SLOWLY
WES Negotiate
BLINKING SLOWLY
(Green)
BLINKING RAPIDLY
(Green)
WES Success
LED (Green) ON
LED (Green) ON
WES Fail/Timeout
LED (Green) OFF
LED (Green) OFF
7
Console Port
To access EAP210 via the console interface
