4RF Aprisa SR+ - Layer 2 Filter; Moxa RTU; Laptop

12 | Default Configurations
Aprisa SR+ Demo Kit Guide 1.3.0
Layer 2 Filter
Layer 2 Filter
enabled
Layer 2 Filter Rules
Source
MAC Address
Destination
MAC Address
Protocol Type
Allow ARPS
FF:FF:FF:FF:FF:FF
FF:FF:FF:FF:FF:FF
ARP
Allow Unicasts from ANY source
FF:FF:FF:FF:FF:FF
FE:FF:FF:FF:FF:FF
ANY
Moxa RTU
The RTU has been preconfigured to the requirements of this demo kit. However, should the settings be
changed in any way, the parameters can be re-configured by following these steps:
The factory default IP address of the RTU (MOXA ilogik E2124) is 192.168.127.254
1. Open Web browser and enter: 192.168.127.254
2. Navigate to Network Settings > Ethernet Configuration
a. Set the IP address to: 172.17.200.220
b. Set the subnet mask to: 255.255.0.0
c. Set the gateway to: 0.0.0.0
3. Navigate to I/O Settings > D0 Channel Settings
a. Configure D0 channel 3 to Power Settings “ON”
Laptop
Network Connections
Terminal Emulator
Local Area Connection
COM Port Settings
Properties
BaudRate
38400
Internet Protocol TCP/IP Settings
Data
8 bit
IP Address
172.17.200.110
Parity
None
Subnet Mask
255.255.0.0
Stop
1 bit
Default Gateway
0.0.0.0 (none)
Flow Control
None
Advanced TCP/IP Settings
Terminal Settings
WNS
Disable NetBIOS over TCP/IP
ASCII Receiving
CR+LF (line feed after receiving a text file)
Wireless Network Connection
Disable
Character delay
0
Line delay
0
