Know your product
Before using the saw, familiarise yourself with all the
operating features and safety requirements.
1. Saw arm
2. Release knob
3. Operating handle
4. Upper fixed blade guard
5. Rotating blade guard
6. Guard retraction arm
7. Bevel lock
8. Bevel scale
9. 45° Bevel
adjustment screw
10. 0° Bevel
adjustment screw
11. Fence
12. Mitre table
13. Mitre scale
14. Table insert
(kerf plate)
15. Mitre lock
16. Switch trigger
17. Release latch
18. Spindle lock button
19. Blade bolt cover
20. 6mm Hex key
21. Dust extraction port
