11
You may now connect your headboard to the attachment plates
using the remaining short bolts and nuts to secure it to the
brackets. The heads of the bolts will face outward. Use a 9/16"
socket and 1/2" wrench to tighten the bolts.
STEP 2 STEP 3
Attach the plastic spacer and T-Bracket.
a.) Measure the distance between the mounting holes on the
headboard and install the spacer and attachment plate to
accommodate the headboard.
b.) To install the plastic spacer and attachment plate, you will
need 2 (two) long bolts and 2 (two) nuts. Place the spacer
and attachment plate in the desired location and slip the bolts
through the holes with the head of the bolt facing outward.
Position the bolts diagonally on the spacer. Use the 9/16” socket
and wrench to tighten the bolts.
headboard bracket installation guide
For customer support, visit www.ahbeard.com or call: 1300 654 000
