If any split setup is being installed, plastic connecting straps are provided (one per base) to secure
the bases together. Use both straps to secure the head and foot portions together.
With the bases in their
desired location, slightly
loosen both legs to allow
the strap to fit on the
leg bolt, between the leg
washer and frame.
Slide side (a) of the connecting strap onto leg bolt. Swing the strap
and connect side (b) to the leg bolt. Secure the strap by shifting to
the left.
Re-tighten legs. Do not over tighten. Use the remaining strap and
repeat on other end of the base.
STEP 2
STEP 1
STEP 3
a b
setting up two bases
For customer support, visit www.ahbeard.com or call: 1300 654 000
