15
SERIAL PORT SERIAL PORT
Unplug base from power source.
Disconnect the power-down box cable from each control box. Make
note where the cable was plugged in.
Connect the male end of each sync cord to control box. Insert it into
the same port that you disconnected the power-down box from in
Step 2.
Connect each power-down box male connection to the sync cord
female connection (Refer to the illustration below).
Plug base back into the power source.
Check to ensure all cords are securely attached. Both remotes will
now operate both bases simultaneously (If the remotes become
unpaired, see page 13).
STEP 1
STEP 2
STEP 3
STEP 4
STEP 5
STEP 6
Power-Down Box Power-Down Box
Sync Cord
Splitter
Splitter
Control Box
Control Box
If simultaneous operation of two bases is desired, use the SmartSync
™
Cord to connect the
electronics of both bases together.
setting up two bases
