10
STEP 1
a.) Align the hole in the bracket to the brass sleeve into which the
leg threads. Hold the bracket in place and screw the leg into the
base until it is snug. DO NOT OVERTIGHTEN. Too much force
may cause the leg to spin freely.
b) Align the tab with the hole in the frame (located towards the
foot of the base) and use a short bolt and nut to secure the
bracket. Make sure the bolt is tight.
A 9/16” & 1/2” socket and crescent wrench are necessary to complete installation.
headboard bracket installation guide
HEADBOARD BRACKET COMPONENTS
Headboard Bracket (2) T-Bracket (2) Spacer (2) Long Bolt (8) Short Bolt (10) Nut (18)
For customer support, visit www.ahbeard.com or call: 1300 654 000
Headboard Brackets are an optional accessory and can be purchased separately.
