A.O. Smith CAHP-120C Series User Manual

4
2 Physical and Technical Specifications
2.1 CAHP-80 Physical and Technical Specifications
Figure 2.1 Figure 2.2
Table 2.1 Physical Dimensions
Total
Height
A (mm)
Tank
Diameter
B (mm)
Maximum
Depth
C (mm)
Service
Panel Width
D (mm)
Relief Valve
Height
E (mm)
Water Outlet
Height
F (mm)
Water Inlet
Height
G (mm)
Relief Valve
Angle Į (°)
Maximum
Width
H (mm)
1670 610 901 503 1457 1427 135 22 686
Table 2.2 Technical Specifications
Model Number CAHP-80-6 CAHP-80-8 CAHP-80-10 CAHP-80-12
Model Type / Outdoor Integrated Heat Pump Water Heater
HP Rated
Power
(1)
380V/3N/60Hz kW 1.25
220V/1N/60Hz kW 1.25
400V/3N/50Hz kW 0.98
230V/1N/50Hz kW 0.98
HP Rated
Heating
Capacity
(1)
380V/3N/60Hz kW 4.13
220V/1N/60Hz kW 4.13
400V/3N/50Hz kW 3.5
230V/1N/50Hz kW 3.5
Unit Maximum 380V/3N/60Hz kW 9.7 (5.9)
(2)
12.3 (7.2) 14.8 (8.5) 17.4 (9.7)
