A.O. Smith CAHP-120C Series User Manual

5
Power 220V/1N/60Hz kW 9.7 (5.9)
(2)
12.3 (7.2) 14.8 (8.5) 17.4 (9.7)
400V/3N/50Hz kW 9.3 (5.5)
(2)
11.9 (6.8) 14.4 (8.1) 17.0 (9.3)
230V/1N/50Hz kW 9.3 (5.5)
(2)
11.9 (6.8) 14.4 (8.1) 17.0 (9.3)
Unit Maximum
Heating
Capacity
380V/3N/60Hz kW 10.13 (7.13) 12.13 (8.13) 14.13 (9.13) 16.13 (10.13)
220V/1N/60Hz kW 10.13 (7.13) 12.13 (8.13) 14.13 (9.13) 16.13 (10.13)
400V/3N/50Hz kW 9.5 (6.5) 11.5 (7.5) 13.5 (8.5) 15.5 (9.5)
230V/1N/50Hz kW 9.5 (6.5) 11.5 (7.5) 13.5 (8.5) 15.5 (9.5)
Maximum
Operation
Current
380V/3N/60Hz A 15.8 21 26.3 31.5
220V/1N/60Hz A 41.6 (25.8) 52 (31) 62.6 (36.3) 73 (41.5)
400V/3N/50Hz kW 15.8 21 26.3 31.5
230V/1N/50Hz A 39.1 (23.3) 49.5 (28.5) 60.1 (33.8) 70.5 (39)
Refrigerant
/
R134a
Refrigerant
Charge Quantity
50Hz g 1000
60Hz g 1100
Electrical Heating Capacity kW 6 (3) 8 (4) 10 (5) 12 (6)
Tank Capacity L 300
Hot Water
Delivering Rate
/ Efficiency
380V/3N/60Hz L/h 89 89 89 89
220V/1N/60Hz L/h 89 89 89 89
400V/3N/50Hz L/h 75 75 75 75
230V/1N/50Hz L/h 75 75 75 75
Hot Water
Delivering Rate
/ High Demand
380V/3N/60Hz L/h 218 (153.5) 261 (175) 304 (196.5) 347 (218)
220V/1N/60Hz L/h 218 (153.5) 261 (175) 304 (196.5) 347 (218)
400V/3N/50Hz L/h 204 (139.5) 247 (161) 290 (182.5) 333 (204)
230V/1N/50Hz L/h 204 (139.5) 247 (161) 290 (182.5) 333 (204)
Max. Water Temperature
In Efficiency Mode
ć
65
Operation Temperature Range
ć 3582
Ambient Temperature for HP
ć 548
Ambient Temperature for Unit
ć -1550
Unit Operation Noise
(3)
dB(A) 52 (50Hz) / 57 (60Hz)
Air Outlet Noise
(3)
dB(A) 58 (50Hz) / 60 (60Hz)
Dimensions (LhWhH)
mm
901h686h1670
Net Weight kg 165
Operation Weight kg 465
Anode / Aluminum Rod, Magnesium Rod
Control Mode / LCD Wire Display (Standard 10m, Optional Maximum 30 m)
Operation Mode / Efficiency, High Demand
Other Control Functions / Timer, Anti freezing, Fault Alarming, Water Pump Controlling
Power Supply Specification / 220V/1N/60Hz&380V/3N/60Hz&230V/1N/50Hz&400V/3N/50Hz
Connection
Size
Water Inlet / NPT 3/4 (Female Thread)
Water Outlet / NPT 3/4 (Female Thread)
T&P Relief Valve / NPT 3/4 (Female Thread)
Drain Valve / NPT 3/4 (Female Thread)
