REPAIR PARTS
REPAIR PARTS
Item
No.
Parts Description
1 DRAFT HOOD
2
REDUCER RING - SOME MODELS
(NOT SHOWN)
3 FLUE BAFFLE (NOT SHOWN)
4 COMBINATION DIP TUBE/HEAT TRAP NIPPLE
5 HEAT TRAP/NIPPLE
6
ANODE ROD - SOME MODELS
7 COMBINATION HEAT TRAP NIPPLE/ANODE
- SOME MODELS
8 TEMPERATURE & PRESSURE RELIEF VALVE
(LOCATED TOP OR SIDE)
9 DRAIN VALVE
10 GAS CONTROL VALVE/THERMOSTAT
(with thermal switch wire lead)
11
OUTER DOOR
12
PILOT/THERMOPILE ASSEMBLY KIT
13
FINAL BURNER ASSEMBLY
14
MANIFOLD DOOR GASKET
15 WRAP AROUND AIR FILTER
REPAIR PARTS LIST
Replacement parts may be ordered through your plumber or
the local distributor. Parts will be shipped at prevailing prices
and billed accordingly.
NOTICE: When ordering replacement parts, have the following
informa on ready:
• Model and serial number
• Type of gas used
• Item number
• Parts descrip on
Legend
▲ Special anode rod (see page 26)
■ Temperature and Pressure Relief Valve is required but may
be factory installed
★ Unique: Flammable Vapor Igni on Resistant Safety System
parts
