40
Maintenance schedule Assembly inspection at 0 km
No. Step
Assembly inspection
1 Assembly: Frame-Handlebars-Stem-Seat post-Saddle
Check the units for cracks and replace as necessary Screw inspection at handlebar/stem/saddle X Clean & grease seat post down tube
2 Front fork
Clean entire suspension fork, especially the sliding surfaces of the stanchions Inspect the stanchions for damage and replace as necessary
3 Rear wheel mount
Use air to clean TMM4 sensor without disassembly Check force fit & condition of the sensor plate X Check axle screw fitting for force fit X
4 Assembly: Crank - inside bearing pedal 
Clean crank & pedal / grease pedal spindle Inspect the sprocket for damage and replace as necessary Check the crank and pedal attachment for force fit X Check bottom bracket bearing for play and replace as necessary Detach bottom bracket bearing, clean & grease housing & screw thread
5 Assembly: Chain-Cassette-Sprocket
Clean all parts. Check all screws for force fit X Inspect units for wear and replace as necessary Clean & grease chain
6 Assembly: Wheels-Rims-Tyres 
Clean parts Check tyres for damage and profile depth Correct tyre inflation pressure X Inspect front & rear wheel rim for lateral and radial run-out and correct as necessary Check spoke tension and correct as necessary Check the function & bearing play of the front wheel hub. Detach hub and clean and grease
