A2Z Ozone MP-3000 - Features; Unit Components and Controls

Features
1
Ozone Light
Indicates ozone is functioning. If the LED is illuminated, the unit is
working properly.
2
Power Light
Indicates when there is power to the unit. If the power is supplied,
the light will remain illuminated.
3
O
3
Switch
Used to control ozone power within the unit.
4
Air Pump
Switch
Used to power on the small internal air compressor built into the
unit. If using oxygen supply, DO NOT turn on air pump switch.
5
O
3
Out Port
Ozone produced by the unit exits through this port.
6
O
2
In Port
Optional hook up port for an external oxygen source. This can be
used to produce a more pure ozone. 3 psi & 2-4 LPM flow rate.
7
Air Out Port
Air outlet port for the air compressor (loops into O
2
In Port for
ambient air use).
8
Timer (Hour)
Sets a time limit for the unit to produce ozone. The unit timer
needs to be engaged for ozone production.
9
Ozone
Concentration
Knob
Controls the percentage of ozone produced by the unit.
4
