1-1
Chapter 1: General information
1.1 Package contents
Check your industrial motherboard package for the following items.
1 x Industrial Motherboard
1 x Cable Kit
1 x I/O Shield
1 x DVD-ROM for manual (in PDF format) and drivers
NOTE: If any of the above items is damaged or missing, contact your
distributor or sales representative immediately.
1.2 Features
• Intel
®
Socket 1155 For 2nd Generation Core™ i7/Core™ i5/Core™ i3
Processors Up To 95W
• Two 240-pin Dual Channel DDR3 1066/1333MHz (1600 MHz for 3rd
Generation Core™ Processors) DIMM Up To 16GB
• Three Independent Display: VGA x 1 , HDMI x 3
• 10/100/1000Base-T x 2
• SATA 6.0 Gb/s x 1, SATA 3.0 Gb/s x 2, USB3.0 x 4, USB2.0 x 10, COM x 2
• PCI-Express[x16] x 1
• Onboad TPM Function
• EuP/ErP Compliance
Chapter 1
Product overview
