Aaeon IMBM-Q170A - PCH-FW Configuration; SIO Configuration

3-5
Chapter 3: BIOS setup
3.3.5 PCH-FW Configuration
Firmware Update Configuration
Me FW Image Re-Flash [Disabled]
This item allows you to enable or disable Me FW Image Re-Flash function.
Congurationoptions:[Disabled][Enabled]
3.3.6 SIO Configuration
TheitemsinthismenuallowyoutocongureSuperIOsettings.
[*Active*] Serial Port 1
Use this device [Enabled]
Allowsyoutoenableordisablethislogicaldevice.Congurationoptions:
[Enabled] [Disabled]
The following two items appear only when you set Use this device to
[Enabled].
Possible [Use Automatic Settings]
AllowsyoutoselectanoptimalsettingforSuperI/Odevices.Conguration
options: [Use Automatic Settings] [IO=3F8h; IRQ=4;] [IO=2F8h; IRQ=3]
Mode [RS-232]
AllowsyoutoselecttheSerialPortmode.Congurationoptions:[RS-232]
[RS-422] [RS-485]
[*Active*] Serial Port 2
Use this device [Enabled]
Allowsyoutoenableordisablethislogicaldevice.Congurationoptions:
[Enabled] [Disabled]
Possible [Use Automatic Settings]
This item appears only when you set Use this device to [Enabled] and
allowsyoutoselectanoptimalsettingforSuperI/Odevices.Conguration
options: [Use Automatic Settings] [IO=2F8h; IRQ=3] [IO=3F8h; IRQ=4;]
[*Active*] Serial Port 3
Use this device [Enabled]
Allowsyoutoenableordisablethislogicaldevice.Congurationoptions:
