1-1
Chapter 1: General information
1.1 Package contents
Check your industrial motherboard package for the following items.
1 x Industrial Motherboard 1 x SATA 6.0 Gb/s cable (2 in 1 pack)
1 x I/O Shield 1 x COM port cable (w/bracket)
1 x Support DVD
If any of the above items is damaged or missing, contact your distributor or
sales representative immediately.
1.2 Features
• Intel
®
Socket 1151 for 6th Generation (Skylake-S) Core™ i7/Core™ i5 / Core™
i3, Pentium
®
14nm LGA 1151 socket Processor
• Four 288-pin Dual Channel DDR4 2133/1866MHz DIMMs up to 64GB
• 1 x Intel® PHY i219LM Giga LAN (support Intel® AMT 11.0); 1 x Intel® i211AT
Giga LAN, RJ45 x 2
• 6 x SATA III (6.0Gb/s) ports, Supports RAID 0/1/5/10
• PCI-Express 3.0/2.0 [x16] x 1, PCI-Express 3.0/2.0 [x4] (open edge) x 1, PCI-
Express 3.0/2.0 [x1] (open edge) x 1, PCI x 1
Chapter 1
Product overview
