57
Title block and end block
When weight values are recorded as GLP data, a “Title block” is inserted at the beginning and an
“End block” is inserted at the end of a group of weight values in the GLP report.
Note
To output the report to an AD-8121B , use MODE 3 of the AD-8121B.
Caution
If the data memory function is used, the “Title block” and “End block” can not be output.
Operation
1 With the weighing data displayed, press and hold the PRINT key, then release the key.
S5tart is displayed. The “Title block” is output.
2 The weighing data is output according to the parameter setting of the data output mode.
3 Press and hold the PRINT key until recend is displayed, then release the key. The “End
block” is output.
When the setting is “info 1”: When the setting is “info 2”:
