AAON CL SERIES - Cl Series Startup Form

37
CL STARTUP FORM PAGE 1 of 2
DATE:___________________
JOB NAME:_________________________________________________________________________________________
ADDRESS:_________________________________________________________________ MODEL No:______________
CITY, STATE:______________________________________________________________ SERIAL No:______________
START-UP CONTRACTOR:___________________________________________________ TAG:____________________
PRE START-UP CHECKLIST
Installing contractor shall verify the following items (cross out items that do not apply).
1. Is there any visible shipping damage?__________________________________________________ Yes No
2. Is the unit installation level?__________________________________________________________ Yes No
3. Are the unit clearances adequate for service and operation?_________________________________ Yes No
4. Do all access doors open freely and are the handles operational?_____________________________ Yes No
5. Have all shipping braces been removed?________________________________________________ Yes No
6. Have all electrical connections been tested for tightness?___________________________________ Yes No
7. Does the electrical service correspond to the unit nameplate?________________________________ Yes No
8. Has the overcurrent protection been installed to match unit nameplate requirement?______________ Yes No
9. Have all set screws on fans been tightened?______________________________________________
Yes
No
10. Do all fans and pumps rotate freely?___________________________________________________
Yes
No
UNIT CONFIGURATION
AIR COOLED__________
EVAPORATIVE COOLED _____ NO WATER LEAKS ___ CONDENSER SAFETY CHECK_______
COOLING TEST
COMPRESSORS CRANKCASE
AMPS HEATER
NUMBER MODEL #
L1 L2 L3 AMPS
1
2
3
4
5
6
7
8
AMBIENT TEMPERATURE
AMBIENT DRY BULB TEMP_______________°F AMBIENT WET BULB TEMP_______________°F
