SA Series Feature String Nomenclature
GEN
SIZE
VLT
CONFIG
A1
A2
A3
A4
B1
B2
B3
1A
1B
1C
1D
2
3
4
5A
5B
5C
6A
6B
6C
7
8
9
10
11
12
13
14A
14B
15
SA
-
035
-
3
-
A
-
E
R
0
9
-
0
0
0
:
A
C
0
0
-
0
0
0
-
E
B
F
-
A
B
0
-
0
0
0
0
0
0
0
-
H
A
-
0
0
0
0
0
0
0
0
B
16
17
18
19
20
21
22
23
12
B1: Heating Type
0 = No Heating
C = Steam Distributing Standard Coil
D = Steam Distributing Polymer E-Coated Coil
E = Hot Water Standard Coil
F = Hot Water Polymer E-Coated Coil
B2: Heating Designation
0 = No Heating
H = 1 Row Coil
J = 2 Row Coil
B3: Heating Stages
0 = No Heating
H = Single Serpentine 8 fpi
J = Half Serpentine 8 fpi
K = Single Serpentine 10 fpi
L = Half Serpentine 10 fpi
M = Single Serpentine 12 fpi
N = Half Serpentine 12 fpi
1A: Return / Outside Air Section
0 = Standard
A = Waterside Economizer - 4 Row Coil
B = Waterside Economizer - 6 Row Coil
1B: Plenum Height
0 = 33” Plenum Height
A = 37” Plenum Height
B = 41” Plenum Height
C = 45” Plenum Height
D = 49” Plenum Height
E = 53” Plenum Height
F = 57” Plenum Height
G = 37” Plenum Height + Sound Attenuation
H = 41” Plenum Height + Sound Attenuation
J = 45” Plenum Height + Sound Attenuation
K = 49” Plenum Height + Sound Attenuation
L = 53” Plenum Height + Sound Attenuation
M = 57” Plenum Height + Sound Attenuation
1C: Discharge Configuration
0 = Right - Horizontal Discharge
A = Left - Horizontal Discharge
B = Back - Horizontal Discharge
C = Top - Vertical Discharge
D = Options 0 + A
E = Options 0 + B
F = Options 0 + C
G = Options A + B
H = Options A + C
J = Options B + C
K = Options 0 + A + B
L = Options 0 + A + C
M = Options 0 + B + C
N = Options A + B + C
P = Options 0 + A + B + C
1D: Waterside Economizer Circuiting
0 = Standard - None
E = Single Serpentine 12 fpi
2: Blank
0 = Standard
3: Blank
0 = Standard
4: Maintenance Options
0 = Standard
A = Blower Aux. Contact - Low Voltage Terminal
Block
B = Remote Start/Stop Terminals - Low Voltage
Terminal Block
C = Options A + B
