Installation, Administration and Maintenance
Aastra Telecom Page: 20 (47)
yiaddr IP-Address of the IP-RFP yes
Code 66 Parameter named Boot Server Host Name with
value as the IP-Address of the TFTP server
yes
Code 67 Parameter named Bootfile Name with value of
the path (optional) and name of the application
image. For example omm_ffsip.tftp.
yes
code 1 Subnet mask yes
code 3 Default Gateway yes
code 6 Domain Name Server No
code 15 Domain Name No
code 42 IP-Address of a NTP server No
code 43 Vendor Specific Options yes
public option 224 Parameter named magic_str must set to value
"OpenMobility".
yes
The Vendor Specific Options consist of:
Vendor Specific
Option
Meaning Mandatory
option 226 ommip: Used to select the IP-RFP who should
reside the Open Mobility Manager (OMM)
yes
option 7 syslogip: IP-Address of a Syslog Daemon No
option 15 syslogport: Port of a Syslog Daemon No
option 17 Country: Used to select the country in which the
OMM resides. This enables country specific
tones (busy tone, dial tone, ...)
No
option 18 ntpservname: Name of a NTP Server No
An example of the minimal contents for the Option 43 parameter value would be:
11 02 00 01 0a 04 C0 A8 00 01 where C0 A8 00 01 represents 192.168.0.1 for the OMM IP
Tones for the following countries are supported:
country
code
country
1 Germany
2 Great Britain
3 Suisse
4 Spain
6 Italy
7 Russia
8 Belgium
9 Netherlands
10 Czechia
14 Finland
16 Poland
25 Taiwan
100 North America
101 France
3.1.4.1 Booter update
3.1.4.1.1 Automatic booter update
