Fault tracing 49
3236 PM DC link
capacitors
not balanced
The series connected
capacitors in the DC
link of a PM are
heavily unbalanced.
Check the event log for an auxiliary
code.
The code indicates which PM is
affected.
Replace the faulty PM.
3239 PM diode
open circuit
PM rectifier's diode
open
circuit is
detected.
Check the event log for an auxiliary
code.
The code indicates which PM is
affected.
Replace the faulty PM.
3333 Ground fault The common mode
motor
voltage of the
drive has
exceeded
internal fault limit.
Check for drive internal ground faults
(secondary cabling, PMs,
transformer,
terminal unit).
Check for drive external ground
faults
(motor cable, motor windings).
Check the HVD board.
4100 Ambient
temperature
Ambient temperature
is
too high.
Check for proper cooling of the
control
unit cabinet.
5012 PM HB1 or
HB2 short
circuit turn off
The desaturation
detection of the
IGBTs in HB1 (half
bridge 1) or HB2 (half
bridge 2) of a PM has
detected a short
circuit.
Check the event log for an auxiliary
code.
The code indicates which PM is
affected.
Check converter output terminals for
a
phase to phase short circuit.
Replace the faulty PM.
7538 Control hub
missing
PM
A PM in the converter
does not send data
to the control hub
(PM Tx channel fault).
Check the event log for an auxiliary
code. The code indicates which PM is
affected.
Check POF wiring to the PM (or
replace).
Check control hub daughter board
(or
replace).
Replace the PM.
E108 AC500
communica-
tion
fault
The watchdog
supervision of the
communication link
between BCU and
AC500 has detected a
communication
failure.
Check Modbus cable.
Check FSCA-01 module.
Check setting of parameter groups
54
FBA B settings, 55 FBA B data in
and 56
FBA B data out (changes
allowed only by
ABB authorized
personnel).
Note: Make sure that up to maximum
of
two fieldbus extension modules
are used
on the BCU.
