52 Replace the memory unit and SD card
1. Undo the fastening screw of the clip covering the memory card and press the
card to remove it. For the card location, see the following figure.
2. Insert the new card in reverse order.
replacement illustration
1
3
4
2
1
1 Real-time clock battery
2 Fastening screws for ZMU
3 Fastening screw for SD card
4 Indication LEDs
