Electrical installation

Fasten the

control

cables

between

these plates

with cable

ties

Motor cable

U2 V2 W2

U1 V1 W1

Input power cable

UDC+

- R+ UDC-

Frame sizes R2 to R4

Fastening screws

Fastening hooks

Cover

Bottom plate

Grommet

360 degrees grounding

clamp

Control cable entry

Back plate

Input cable entry

Motor cable entry

Brake resistor cable entry

Connection box (IP21)
