Start-up with medium voltage stator 61
Check grid-side converter mains voltage measurement phase
sequence:
Monitor the following grid-side converter signals with DriveWindow
datalogger with 1 ms time level, when grid-side converter is started:
NUIM board in use (grid-side converter control program
IXXR72xx):
138.02 FLUX X NET ACT
138.03 FLUX Y NET ACT
161.04 FLUX X ACT
161.05 FLUX Y ACT
Start DriveWindow datalogger and trigger manually. Upload
datalogger information:
If parameter 138.02 FLUX X NET ACT and 161.04 FLUX X ACT
signals are in phase and parameter 138.03 FLUX Y NET ACT and
161.05 FLUX Y ACT signals are in phase, the flux measurement is
OK.
See grid-side converter
parameter list:
16.03 PASS CODE
138.02 FLUX X NET ACT
138.03 FLUX Y NET ACT
161.04 FLUX X ACT
161.05 FLUX Y ACT
NAMU / BAMU board in use (grid-side converter control program
IWXR74xx):
02.22 FLUX X NET ACT
02.23 FLUX Y NET ACT
02.20 FLUX X ACT
02.21 FLUX Y ACT
Start DriveWindow datalogger and trigger manually. Upload
datalogger information:
If parameter 02.22 FLUX X NET ACT and 02.20 FLUX X ACT signals
are in phase and parameter 02.23 FLUX Y NET ACT and 02.21
FLUX Y ACT signals are in phase, the flux measurement is OK.
Note: If this test fails, grid-side converter grid voltage cabling must be
checked. See the converter hardware manual.
02.22 FLUX X NET ACT
02.23 FLUX Y NET ACT
02.20 FLUX X ACT
02.21 FLUX Y ACT
Check the grid-side converter parameters. See ACS800-67(LC)
doubly-fed induction generator control program firmware manual
[3AUA0000071689 (English)].
Stop the grid-side converter by setting parameter 21.01 ISU LOCAL
CTR WORD to 0.
Check the grid-side converter parameters. See chapter ACS800-
67(LC) doubly-fed induction generator control program firmware
manual [3AUA0000071689 (English)].
21.01 ISU LOCAL CTR
WORD
Disable the main circuit breaker function by setting parameter 21.02
DISABLE MCB CLOSE to YES (the rotor-side converter
synchronizes to the grid but does not close the main circuit breaker).
21.02 DISABLE MCB
CLOSE
Start the converter with zero speed with the DriveWindow START
button.
Check crowbar measurements after the DC link has been charged:
Measurements are OK, if parameter 06.11 CB BRIDGE VOLTAGE
and 06.12 CB IGBT VOLTAGE values are higher than the DC link
voltage (01.10 DC VOLTAGE) and parameter 06.13 CB IGBT TEMP
value is approximately 25…40 °C.
06.11 CB BRIDGE
VOLTAGE
06.12 CB IGBT VOLTAGE
06.13 CB IGBT TEMP
Stop the converter with the DriveWindow STOP button.
