ABB ACS880-17 Hardware Manual

174 Technical data
Frame sizes and power module types
Drive type
ACS880-37-…
Frame size
Supply module(s)
used
LCL filter(s) used Inverter modules used
Qty
Type
ACS880-104-…
Qty Type Qty
Type
ACS880-104-…
U
N
= 400 V
0450A-3 1×R8i + 1×R8i 1 0470A-3 1 BLCL-13-5 1 0470A-3+E205
0620A-3 1×R8i + 1×R8i 1 0640A-3 1 BLCL-13-5 1 0640A-3+E205
0870A-3 1×R8i + 1×R8i 1 0900A-3 1 BLCL-15-5 1 0900A-3+E205
1110A-3 2×R8i + 2×R8i 2 0640A-3 1 BLCL-24-5 2 0640A-3+E205
1210A-3 2×R8i + 2×R8i 2 0640A-3 1 BLCL-24-5 2 0640A-3+E205
1430A-3 2×R8i + 2×R8i 2 0760A-3 1 BLCL-24-5 2 0760A-3+E205
1700A-3 2×R8i + 2×R8i 2 0900A-3 1 BLCL-25-5 2 0900A-3+E205
2060A-3 3×R8i + 3×R8i 3 0900A-3 2 BLCL-24-5 3 0760A-3+E205
2530A-3 3×R8i + 3×R8i 3 0900A-3 2 BLCL-24-5 3 0900A-3+E205
U
N
= 500 V
0420A-5 1×R8i + 1×R8i 1 0440A-5 1 BLCL-13-5 1 0440A-5+E205
0570A-5 1×R8i + 1×R8i 1 0590A-5 1 BLCL-13-5 1 0590A-5+E205
0780A-5 1×R8i + 1×R8i 1 0810A-5 1 BLCL-15-5 1 0810A-5+E205
1010A-5 2×R8i + 2×R8i 2 0590A-5 1 BLCL-24-5 2 0590A-5+E205
1110A-5 2×R8i + 2×R8i 2 0590A-5 1 BLCL-24-5 2 0590A-5+E205
1530A-5 2×R8i + 2×R8i 2 0810A-5 1 BLCL-25-5 2 0810A-5+E205
1980A-5 3×R8i + 3×R8i 3 0810A-5 2 BLCL-24-5 3 0740A-5+E205
2270A-5 3×R8i + 3×R8i 3 0810A-5 2 BLCL-24-5 3 0810A-5+E205
U
N
= 690 V
0320A-7 1×R8i + 1×R8i 1 0340A-7 1 BLCL-13-7 1 0340A-7+E205
0390A-7 1×R8i + 1×R8i 1 0410A-7 1 BLCL-13-7 1 0410A-7+E205
0580A-7 1×R8i + 1×R8i 1 0600A-7 1 BLCL-15-7 1 0600A-7+E205
0660A-7 2×R8i + 2×R8i 2 0410A-7 1 BLCL-24-7 2 0410A-7+E205
0770A-7 2×R8i + 2×R8i 2 0410A-7 1 BLCL-24-7 2 0410A-7+E205
0950A-7 2×R8i + 2×R8i 2 0600A-7 1 BLCL-25-7 2 0530A-7+E205
1130A-7 2×R8i + 2×R8i 2 0600A-7 1 BLCL-25-7 2 0600A-7+E205
1450A-7 3×R8i + 3×R8i 3 0600A-7 2 BLCL-24-7 3 0530A-7+E205
1680A-7 3×R8i + 3×R8i 3 0600A-7 2 BLCL-24-7 3 0600A-7+E205
1950A-7 4×R8i + 4×R8i 4 0600A-7 2 BLCL-25-7 4 0600A-7+E205
2230A-7 4×R8i + 4×R8i 4 0600A-7 2 BLCL-25-7 4 0600A-7+E205
2770A-7 6×R8i + 5×R8i 6 0600A-7 3 BLCL-25-7 5 0600A-7+E205
3310A-7 6×R8i + 6×R8i 6 0600A-7 3 BLCL-25-7 6 0600A-7+E205
