Parameters 123
03.31 FB A reference 2
int32
Reference 2 received through fieldbus adapter A as a 32-bit
integer.
-
-2147483648 …
2147483647
Reference 2 from fieldbus adapter A. -
03.51 IEC application
panel reference
Panel reference defined in the application program. -
-100000.0 …
100000.0
Panel reference in the application program. 1 = 1
04
04 Warnings and faults
Information on warnings and faults that occurred last.
For explanations of individual warning and fault codes, see
chapter Fault tracing.
All parameters in this group are read-only unless otherwise
noted.
04.01 Tripping fault Code of the 1st active fault (the fault that caused the current
trip).
-
0000h…FFFFh 1st active fault. 1 = 1
04.02 Active fault 2 Code of the 2nd active fault. -
0000h…FFFFh 2nd active fault. 1 = 1
04.03 Active fault 3 Code of the 3rd active fault. -
0000h…FFFFh 3rd active fault. 1 = 1
04.04 Active fault 4 Code of the 4th active fault. -
0000h…FFFFh 4th active fault. 1 = 1
04.05 Active fault 5 Code of the 5th active fault. -
0000h…FFFFh 5th active fault. 1 = 1
04.06 Active warning 1 Code of the 1st active warning. -
0000h…FFFFh 1st active warning. 1 = 1
04.07 Active warning 2 Code of the 2nd active warning. -
0000h…FFFFh 2nd active warning. 1 = 1
04.08 Active warning 3 Code of the 3rd active warning. -
0000h…FFFFh 3rd active warning. 1 = 1
04.09 Active warning 4 Code of the 4th active warning. -
0000h…FFFFh 4th active warning. 1 = 1
04.10 Active warning 5 Code of the 5th active warning. -
0000h…FFFFh 5th active warning. 1 = 1
04.11 Latest fault Code of the 1st stored (non-active) fault. -
0000h…FFFFh 1st stored fault. 1 = 1
04.12 2nd latest fault Code of the 2nd stored (non-active) fault. -
0000h…FFFFh 2nd stored fault. 1 = 1
04.13 3rd latest fault Code of the 3rd stored (non-active) fault. -
0000h…FFFFh 3rd stored fault. 1 = 1
04.14 4th latest fault Code of the 4th stored (non-active) fault. -
0000h…FFFFh 4th stored fault. 1 = 1
No. Name/Value Description Def/FbEq16
