2 System overview
ADS420 cable attached
ADS420 sensor components (cable attached) are shown in
Figure 1:
ADS430
xxxx
xx
Figure 1 ADS420 sensor components (cable attached)
Table 1 Sensor components (cable attached)
Part Description
A
EZLink
™
digital sensor connector
B
Shroud
C
SmartCap (supplied unfitted in sealed factory-supplied container)
Note. The SmartCap serial number is programmed on the memory
chip inside the SmartCap.
D
Sensor body (including temperature sensor)
E

ADS420 cable detached
ADS420 sensor components (cable detached) are shown in
Figure 2:
Figure 2 ADS420 sensor components (cable detached)
Table 2 Sensor components (cable detached)
Part Description
A
EZLink digital sensor connector
B
Shroud
C
SmartCap (supplied unfitted in sealed factory-supplied container)
Note. The SmartCap serial number is programmed on the memory
chip inside the SmartCap.
D
Sensor body (including temperature sensor)
