ABB Advance Optima caldos27 User Manual

3-2 Chapter 3: Gas Line Connection 42/24-10 EN Rev. 9
Magnos27: Gas Connections
Figure 3-2
1
2
3
4567
8
9
10
11
12
14
13
1 Purge Gas Inlet Housing
1)
2 Purge Gas Outlet Housing
1)
(also with Flow Sensor)
3 –
4 Sample Gas Inlet
5 Purge Gas Inlet Analyzer
6 Purge Gas Outlet Analyzer
7 Sample Gas Outlet
8 –
9 Pressure Sensor 1
1)
10 Pressure Sensor 2
1)
Pneumatics Module
1)
:
11 Sample Gas Inlet
12 End Point Gas Inlet (with 3 solenoids)
13 Test Gas/Zero-Point Gas Inlet (with 1 or 3 solenoids)
14 Sample Gas Outlet – Connect with Inlet 4
Gas Connections
1) Option
